Greater energy availability with the 2 kWh battery pack.
Precise and optimized control thanks to the adjustable output from 0-800W.
Automatic: Fully automatic power control with smart meter connection
Night/Day Timer: Assisted hourly power configuration
Volume energy density > 83Wh/L: lots of energy in a small space
Hypontech, Envertech, Deye, AP systems, NEP, Hoymiles, OSDA, etc
PV
Jet Vols
Micro Inverter
Smart meter
Grid
Load
Wifi transmitter
| Model | MH7A-48 |
| Energy | 2016 Wh |
| Nominal Voltage | 48 V |
| Max discharge current | 20A |
| PV input ports (MPPT) | 2 |
| Max PV input power | 1200W |
| PV input voltage range | 11V-60V |
| Round-Trip Efficiency | ≥95% |
| Enclosure Protection | IP65 |
| Operating Temperature | -10℃~45℃ |
| Dimensions (W*H*D) | 371*234*285mm |
| Weight | 27kg |
| Communication | WiFi/Bluetooth |
| Display | LCD |
| Certificate | CE,UN38.3, TUV, IEC62619 EMC, RED, RoHS2.0 |
